S7-1500 CM PTP RS422/485 HF Communication module

Siemens SIMATIC S7-1500 CM PTP RS422/485 HF Communication module 6ES7541-1AB00-0AB0

The Siemens SIMATIC S7-1500 CM PTP RS422 485 HF communication module (part number 6ES7541-1AB00-0AB0) is a high-performance communication module used in the Siemens SIMATIC S7-1500 programmable logic controller.

This module provides two communication interfaces: RS422 and RS485, both of which support point-to-point (PTP) communication. This module also has a high frequency (HF) transmission mode which enables faster communication speed over long distances.

RS422 and RS485 interfaces are commonly used in industrial communications and are capable of transmitting data at high speed over long distances. This module supports multiple communication protocols including Modbus RTU, PROFIBUS DP, and MPI.

CM PTP RS422/485 HF Specifications:

• SIMATIC S7-1500
•  CM PTP RS422/485 HF Communication module for Serial connection RS422 and RS485
•  Freeport, 3964 (R), USS, MODBUS RTU Master, Slave, 115200 Kbit/s, 15-Pin D-sub socket
