MC1391P, TV Horizontal Processor, 16-Pin PDIP
- Integrated Horizontal Processing Functions – Combines oscillator, phase detector, and pre-driver for television applications.
- Internal Shunt Regulator – Provides stable voltage regulation within the circuit.
- Preset Hold Control Capability – Maintains specific operational states for improved stability.
- ±300 Hz Typical Pull-In Range – Ensures precise frequency synchronization.
- Low Thermal Frequency Drift – Reduces frequency variations due to temperature changes.
- Variable Output Duty Cycle – Supports both tube and transistor-driven circuits.
