SIMATIC S7-1500 DQ 32x24V DC/0.5A HF 6ES7522-1BL01-0AB0
SIMATIC S7-1500 DQ 32×24 V DC/0.5A HF 6ES7522-1BL01-0AB0 is a digital output module designed for use with the programmable logic controller (PLC) of the SIMATIC S7-1500 series of Siemens.
This particular module has 32 digital outputs that operate on 24-volt DC signals and are capable of delivering up to 0.5 amps of current. The module also supports high-frequency conversion, ideal for applications requiring fast response times.
DQ 32×24 V DC/0.5A HF Specifications:
- SIMATIC S7-1500,
- digital output module DQ 32x24V DC/0.5A HF
- 32 channels in groups of 8
- 4 A per group
- single channel diagnosis; Substitute value, switching cycle counter for connected actuators
- the module supports the safety-related shutdown of load groups up to SIL2 according to EN IEC 62061:2021 and Category 3 / PL d according to EN ISO 13849-1:2015. Front connector (screw or plug-in terminals) to be ordered separately
