MC74HC30N – 8-Input NAND Gate

The MC74HC30 is identical in pinout to the LS30. The device inputs are compatible with standard CMOS outputs; with pullup resistors, they are compatible with LSTTL outputs

•Output Drive Capability: 10 LSTTL Loads
•Outputs Directly Interface to CMOS, NMOS, and TTL
•Operating Voltage Range: 2 to 6 V
•Low Input Current: 1μA
• High Noise Immunity Characteristic of CMOS Devices
•In Compliance with the Requirements Defined by JEDEC Standard No. 7A
•Chip Complexity: 32 FETs or 8 Equivalent Gates
